Electrical Characteristics
| Dielectric Strength | 3000V |
||
|---|---|---|---|
| Rated Current | |||
| Rated Voltage | 600V AC |
||
| Dielectric Strength | 3000V |
Rated Current | |
| Rated Voltage | 600V AC |
Product Type
| Docking Method | Thread |
||
|---|---|---|---|
| Mounting Type | Panel Mount |
||
| Color | Black, Red |
||
| Orientation | |||
| Terminal Size | N/A |
||
| Terminal Material | Cooper |
||
| Thread diameter(Top/Bottom) | M8/M8 |
||
| Shell Material | PA66 |
||
| Shielding | 360° |
||
| Docking Method | Thread |
Mounting Type | Panel Mount |
| Color | Black, Red |
Orientation | |
| Terminal Size | N/A |
Terminal Material | Cooper |
| Thread diameter(Top/Bottom) | M8/M8 |
Shell Material | PA66 |
| Shielding | 360° |
Mechanical Characteristics
| Insertion Times | > 500 |
|---|---|
| Insertion Times | > 500 |
Environmental Characteristics
| Operating Temperature | -40℃~125℃ |
|---|---|
| Operating Temperature | -40℃~125℃ |
Contact Type
| Contact Finish | Nickel Plating |
|---|---|
| Contact Finish | Nickel Plating |
The High Current Connector Copper Terminal refers to the posts used to connect wires on ammeters, voltmeters, and resistance meters. The terminal blocks are made of environmentally friendly materials, which can reduce impact and avoid falling over time. Professional manufacturing, stable performance and high reliability.
The product adopts a PA66 flame-retardant material shell. It is insulating and flame retardant. The conductive parts are made of brass, which has strong conductivity and is not easy to overheat. The terminal connectors are made of copper, a high-quality material that can ensure the durability and stability of the product so that it can be used for a long time.
Through Wall Power Terminal Drawing
