Product Type
| Terminal | 8mm |
||
|---|---|---|---|
| Connector Type | |||
| Orientation | |||
| Color | Orange |
||
| Wire Gauge | – |
||
| Mounting Type | Cable Mount |
||
| Shell Material | Nylon |
||
| Terminal | 8mm |
Connector Type | |
| Orientation | Color | Orange |
|
| Wire Gauge | – |
Mounting Type | Cable Mount |
| Shell Material | Nylon |
Electrical Characteristics
| Rated Current | |||
|---|---|---|---|
| Rated Voltage | 1000V |
||
| Insulation Resistance | |||
| Rated Current | Rated Voltage | 1000V |
|
| Insulation Resistance |
Contact Type
| Contact Termination | Crimp |
||
|---|---|---|---|
| Contact Finish | Silver Plating |
||
| Contact Termination | Crimp |
Contact Finish | Silver Plating |
Environmental Characteristics
| Operating Temperature | -40°C-125°C |
||
|---|---|---|---|
| Flammability Rating | UL94 V-0 |
||
| Ingress Protection | IP67 |
||
| Operating Temperature | -40°C-125°C |
Flammability Rating | UL94 V-0 |
| Ingress Protection | IP67 |
Mechanical Characteristics
| Mating Cycles | >500 |
|---|---|
| Mating Cycles | >500 |
The energy storage connectors for professional CAE simulations to meet technical specifications such as plugging force, insulation resistance, dielectric strength, and temperature rise.
These connectors link battery modules in series, enhancing worker safety during ESS installation. Industries such as energy storage, new automotive, and others extensively employ these connectors.
Unique Design
ESS designers can use these connectors in series or individually, depending on specific application requirements. The battery storage connector is mounted on the front of the battery module, while the connector is mounted on the back.
The energy storage connectors can be rotated 360 degrees. So they can be adapted to arrange the best angle for heavy cables. They are mechanically coded to prevent polarity reversal and incorrect mating.
Battery storage connectors have a drawer-style slide-in connection that eliminates the need for field wiring. The modular connection system can be scaled to meet application requirements, eliminating wiring limitations and allowing for higher power distribution.
Application
In the field of energy storage, we use a wide range of energy storage connectors covering a variety of application scenarios such as electric vehicle charging, renewable energy systems, industrial energy storage systems and domestic energy storage systems. Their main function is to provide safe and reliable electrical connections for efficient energy transmission and management.
How to Order
Selecting the right connector for your needs is critical to ensuring the stable operation of your energy storage system. Please refer to the product part number rule chart below to help you better understand and select the right connector.
